OUxInfo

OUxInfo is a high-performance Python library for Shannon entropy estimation and information-theoretic causal inference, powered by a C++ backend.

It provides non-parametric k-nearest-neighbor (KSG/Kozachenko-Leonenko) estimators for:

  • Shannon entropy, KL divergence, mutual information, conditional mutual information
  • Transfer entropy and backward transfer entropy
  • Information flow and causal maps
  • Directed spatial information flow (1D and 2D)

The C++ core uses nanoflann for fast k-d tree queries and OpenMP for parallelism, making it suitable for large datasets and multivariate analyses.

Quick Start

pip install ouxinfo

import numpy as np
from ouxinfo import shannon_entropy, transfer_entropy

# Shannon entropy of a standard normal (true value: 0.5 * ln(2πe) ≈ 1.419 nats)
x = np.random.normal(0, 1, 10000).reshape(-1, 1)
H = shannon_entropy(x, k=5)
print(f"H(X) = {H:.3f} nats")

# Transfer entropy from y to x for coupled AR processes
n = 5000
y = np.cumsum(np.random.randn(n)).reshape(-1, 1)
noise = np.random.randn(n).reshape(-1, 1)
x = np.roll(y, 1) * 0.5 + noise * 0.5
TE = transfer_entropy(y, x, tau=1, k=5)
print(f"TE(y -> x) = {TE:.4f} nats/step")

Key Features

Feature Description
KSG estimators k-NN estimators for entropy, MI, CMI, KL divergence
Transfer entropy Forward and backward TE with surrogate testing
Information flow Horowitz-Esposito rate decomposition (IF, Leak, dI)
Causal maps Pairwise TE and IF maps for multivariate systems
Spatial flow Directed information flow across 1D/2D spatial grids
TEIFL All-in-one analysis: sTE, mTE, bTE, IF, Leak, dI
OpenMP Parallelized causal map computation

Theory Overview

All estimators are based on the k-nearest-neighbor (KSG) approach, which is non-parametric and does not assume any distributional form.

Shannon entropy is estimated via the Kozachenko-Leonenko formula:

\[H(X) = \psi(N) - \psi(k) + \log c_d + \frac{d}{N}\sum_{i=1}^{N} \log \epsilon(i)\]

Transfer entropy quantifies directed information flow from source \(Y\) to target \(X\):

\[TE_{Y \to X} = I\!\left(X_{t+\tau};\, Y_t^{(m)} \mid X_t^{(m)}\right)\]

Information flow decomposes the rate of mutual information change:

\[\frac{d}{dt}I(X_t; Y_t) = \dot{I}_X(t) + \dot{I}_Y(t) + \text{Leak}\]

License

MIT License. Third-party components (nanoflann, Boost) are bundled under their respective BSD/Boost licenses.
